Small Computer J6412 12V Watchdog Din Rail Mini PC TDP 10W

Name: Small Computer J6412 12V Watchdog Din Rail Mini PC TDP 10W
Brand: Shenzhen Xin Saike Technology Co.,Ltd.
SKU: IEXP-342
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	SMATIPC
Certification:	CCC,CE,ROHS,ISO9001
Model Number:	IEXP-342

Detail Information

Place of Origin:

China

Brand Name:

SMATIPC

Certification:

CCC,CE,ROHS,ISO9001

Model Number:

IEXP-342

CPU:

J6412

Memory:

DDR4 3200 Max 32gb

M.2:

M.2 2280 M-key Slot

Graphics:

Intel(R) UHD Graphics

Watchdog Suuport:

YES

Installation:

VESA , Wall-mounted, Din-rail

Highlight:

High Light

Highlight:

din rail mini pc

small computer

J6412 mini pc 12v

Trading Information

Minimum Order Quantity:

Price:

Negotiable

Packaging Details:

Each pc for one neutral box

Delivery Time:

3-7Days

Payment Terms:

T/T,Paypal

Supply Ability:

10000 Pcs/Month

Product Description

Small Computer J6412 12V Watchdog Din Rail Mini PC TDP 10W

Key Features:

Intel J6412 quad-core processor (Max Turbo 2.6 GHz)
DDR4 3200 memory support (max 32GB)
M.2 2280 M-key slot for storage expansion
Intel UHD Graphics with triple display support
Watchdog timer for enhanced reliability
Flexible installation options: VESA, wall-mounted, or DIN rail
Energy efficient 12V power supply (TDP 10W)

Technical Specifications

Processor & Memory

CPU: Intel J6412 (quad core)

Clock Speed: Max Turbo 2.6 GHz

Memory: 1 x DDR4 3200 (max 32GB)

Chipset: Elkhart Lake

Graphics & Display

Graphics: Intel UHD Graphics

HDMI: 2 ports (4096x2160 @60Hz)

VGA: 1 port (1920x1080 @60Hz)

Displays: Triple display support

Storage & Expansion

M.2 Slot: 2280 M-key (SATA/PCIE3.0/NVME)

SATA: 1 x 2.5" SSD slot

Mini PCIe: 1 full length slot

Nano-SIM: Supported

Connectivity & I/O

Ethernet: 2 x Gigabit (Intel RTL8111H)

USB: 4 x USB 3.0, 2 x USB 2.0

COM Ports: 4 (RS232/485 optional)

Audio: Line-out/Mic-in combo

Physical Specifications

Dimensions	186 x 127 x 66 mm
Weight	1.36 kg
Installation	VESA, Wall-mounted, DIN rail
Operating Temperature	-20℃ to 60℃
Operating Humidity	5% to 95% non-condensing
Power Input	DC 12V

Applications

This compact yet powerful mini PC is designed for demanding industrial and commercial applications including:

Industrial automation and control systems
Medical equipment and healthcare solutions
Transportation and logistics management
Warehouse and inventory control
Digital signage and kiosk systems
E-learning and education technology
Retail POS and restaurant management

Additional Features

Watchdog timer for system reliability
Power on/Wake on LAN functionality
PXE boot support
TPM 2.0 security module
Energy efficient design (10W TDP)
