Product Description:
The Industrial PC Core boasts an impressive DP resolution of 7680 X 4320 @60Hz, ensuring that you get the best possible visual experience when using high-resolution displays. This feature makes it an ideal choice for applications that require high-quality graphics and visuals, such as digital signage, gaming, and video surveillance.
The Industrial PC Core is powered by the Alder Lake-U chipset, which is designed to deliver exceptional performance and energy efficiency. This chipset is optimized for industrial applications, ensuring that your PC runs smoothly and efficiently even under heavy loads.
Unlike many other industrial PCs, the Industrial PC Core does not come with a COM port as standard. However, this can be easily added as an optional extra if required. This makes it an ideal choice for applications that do not require a COM port, such as digital signage or gaming.
Technical Parameters:
| Parameter |
|
|
Storage |
| Processor |
Intel i5-1235U (10 core 12 threads, Turbo. 4.4 GHz)
Intel i7-1255U (10 core 12 threads,Turbo. 4.7 GHz)
|
|
M.2 |
1x M.2 2280 M-key slot (support SATA SSD & NVME SSD PCEIE 1X ) |
| Chipset |
Alder Lake-U |
|
MSATA |
1xMSATA |
| Memory |
2xDDR5 4800MHz SODIMM, Max 64 GB |
|
Expansion |
| Graphics Card |
|
Mini PCIE |
1xfull-length Mini PCIe slot (support PCIE & USB2.0 signal, 4G/WIFI/Bluetooth optional), internal Nano-SIM card slot |
| Graphics |
Intel(R) Iris(R) Xe Graphics |
|
|
|
| Display |
2xDP(Resolution 7680 x 4320 @60Hz) |
|
Dimension |
| |
|
|
Size |
205 * 146 * 50 mm |
| Network |
|
Weight |
1.54 kg |
| Lan Port |
3xIntel i210-AT, 1xIntel i219-LM 1000M Ethernet |
|
Installation |
Wall-mounted (standard included), Din rail (optional), Desktop (default support) |
| I/O |
|
Environment |
| USB |
4xUSB 3.0 |
|
Temperature |
-20℃~+60℃, Surface air flow |
| COM |
Standard None, Optional 2xCOM (COM1/2 RS232/485) |
|
Humidity |
5%~95% Non-condensing state |
| Audio |
/ |
|
Other Function |
Power-on, Timing boot, Wake on LAN, PXE boot, watchdog (level 0-255), TPM2.0 security encryption |
| Power Supply |
|
|
|
| Power Supply |
1x4Pin Phoenix terminal power supply,
DC 12V~24V wide voltage input
|
|
Application |
Industrial Automation, Medical, Logistics &Transportation, Warehousing, e-education and other fields. |
Applications:
This industrial box PC is suitable for various product application occasions and scenarios. It can be used in industrial automation, such as in manufacturing plants, factories, and warehouses, where it can perform data acquisition and control functions. It can also be used in the transportation sector, such as in airplanes, trains, and buses, where it can provide entertainment systems, navigation, and communication functions.
The IEXP-512 can also be used in the healthcare industry, where it can perform patient monitoring and data analysis. It can also be used in the energy sector, such as in oil and gas exploration, where it can perform real-time data acquisition and analysis. Additionally, the IEXP-512 can be used in the retail industry, such as in kiosks, ticketing machines, and vending machines, where it can provide touch screen interfaces and payment solutions.
The IEXP-512 has a minimum order quantity of one and a negotiable price. It comes packed in a neutral box, and delivery time is between 3-7 days. Payment terms are flexible, with T/T and Paypal options available. SMATIPC has a supply ability of up to 10,000 pcs/month, ensuring that customers can order in bulk. Lastly, the IEXP-512 runs on a DC 12V-24V power supply, ensuring that it can operate in various locations.
