Product Description:
The Core Industrial PC comes equipped with 6 RS-232 serial ports, making it ideal for connecting to a wide range of embedded devices. Serial ports are commonly used in industrial automation, robotics, and other types of embedded devices. This feature ensures that the Core Industrial PC is capable of communicating with a wide range of devices, making it a versatile and valuable asset to any industrial workspace.
In addition to its serial ports, this device also boasts 2 Intel I226-V Ethernet network interfaces. These interfaces provide reliable and high-speed connectivity to your network, ensuring that your device is always connected and ready to perform. This is especially important in industrial applications where network downtime can cause significant disruptions to business operations.
Technical Parameters:
| Parameter |
|
|
Storage |
|
| Processor |
Onboard Intel i5-1235U(ten core twelve thread,4.4 GHz)
Onboard Intel i7-1255U(ten core twelve thread,4.7 GHz)
|
|
M.2 |
1*M.2 2280 M-key slot(support NVME SSD, PCIE X4 protocol) |
| Chipset |
Alder Lake-N |
|
SATA |
1*2.5 inch SSD slot |
| Memory |
1*DDR5 4800MHz SODIMM slot, max 32 GB |
|
Expansion slots |
|
| Graphics Card |
|
|
Mini PCIE |
1* full length Mini PCIe slot(PCIE&USB2.0 protocol,
4G/WIFI/BT optional), inside Nano-SIM slot
|
| Graphics Card |
Integrated Intel(R) UHD Graphics (Support synchronous and asynchronous triple display) |
|
M.2 |
1*M.2 2230 E-key slot( support WiFi / BT) |
| Display port |
2*HD-MI(Resolution up to 3840 x 2160 @60Hz)
1*Type-C(Resolution up to 3840 x 2160 @60Hz)
|
|
Size/weight |
|
| Ethernet |
|
Dimension |
186 * 140 * 66 mm |
| |
|
weight |
X kg |
| Internet port |
2*Intel I226-V 2.5G Ethernet |
|
Installation |
VESA , Wall-mounted, Din-rail (optional) |
| I/O |
|
|
Environmental |
|
| USB |
4*USB 3.0, 2*USB 2.0 |
|
Operating Temperature |
-20℃ ～ +60℃, Surface air flow |
| COM |
6*RS232 COM (standard) |
|
Operating Humidity |
5% ～ 95% Non-condensing state |
| Audio |
1* Line-out/Mic-in, two in one audio |
|
Other Function |
Power on when there is electricity, network wake up
timed startup, PXE startup(0～255level),TPM2.0
|
| Power supply |
|
|
Application |
Industrial automation, medical, transportation, logistics, warehousing, e-education.,etc |
Applications:
SMATIPC IEXP-522 Core Industrial PC is a high-performance computer designed for various industrial applications. It is made in China and comes with CCC, CE, ROHS, and ISO9001 certifications, ensuring its quality and safety. The minimum order quantity for this product is 1, and the price is negotiable.
This industrial PC is capable of handling complex industrial processes, thanks to its 10 core Alder Lake-N chipset and up to 32 GB DDR5 memory. It also features up to 2 TB SSD storage, which provides ample space for storing large amounts of data.
