Intelligent Embedded Computer With Intel 12th Gen Intel Core I3

Name: Intelligent Embedded Computer With Intel 12th Gen Intel Core I3
Brand: Shenzhen Xin Saike Technology Co.,Ltd.
SKU: IEXP-732
Availability: InStock

Product Details:

Place of Origin:	China
Brand Name:	SMATIPC
Certification:	CE, FCC, CCC
Model Number:	IEXP-732
Document:	IEXP-732 Ver 1.0.pdf

Detail Information

Place of Origin:

China

Brand Name:

SMATIPC

Certification:

CE, FCC, CCC

Model Number:

IEXP-732

Document:

IEXP-732 Ver 1.0.pdf

Product Collection:

12th Generation Intel Core I3 Processors

CPU:

I3-12300T

Total Cores:

Total Threads:

Chipset:

H610

Processor Base Power:

35 W

Humidity:

5%~95%

Power Supply:

DC 12V-19V Input

Highlight:

High Light

Highlight:

intel embedded pc

intel embedded computer

i3 embedded pc

Trading Information

Minimum Order Quantity:

Price:

Negotiable

Delivery Time:

5-7 Days

Payment Terms:

T/T,Paypal

Supply Ability:

9000 Pcs/Month

Product Description

Intelligent Embedded Computer With Intel 12th Gen Intel Core I3

Product Description:

. The IEXP-732 is suitable for use in a variety of harsh environments. It can withstand temperature extremes of -20°C to 60°C and humidity levels ranging from 5% to 95%. Its weight of 3.27kg makes it easy to install and transport. And it support for up to 64GB of DDR4 memory. This allows you to tailor the system to your specific needs and ensure that it can handle even the most demanding applications. The Realtek RTL8111H LAN type provides reliable and fast network connectivity

Technical Parameters:

Parameter		Storage
Processor	Intel Core i3-12300T (4 core 8 threads, Max 4.2GHz) Intel Core i5-12500T (6 core 12 threads, Max 4.4 GHz) Intel Core i7-12700T (12 cores 20 threads, Max 4.7GHz)	M.2	1xM.2 2280 M-key slot ( support PCIE3.0 x4 NVME) (support SATA SSD requires resistor switching signal)
Chipset	H610	SATA	1x2.5 inch HDD
Memory	2xDDR4 3200MHz SODIMM slot, Max 64 GB	Expansion
Graphics Card		Mini PCIE	1xfull-length Mini PCIE slot (support PCIE & USB2.0 singal, Optional 4G/WIFI/BT), internal Nano-SIM card slot
Graphics	Integrated Intel® UHD Graphics 730/770 (synchronous/asynchronous dual display)
Display	1xHDMI Port (Resolution 3840x2160 @60Hz) 1xVGA (Resolution 1920x1080 @60Hz)	Dimension
		Size	215 x 203 x 75 mm 8.46 x 8.0 x 3.0 inch
Ethernet Network		Weight	3.27 kg (Barebone) 7.2lb
Lan Port	2xRealtek RTL8111H Gigabit LAN	Installation	Wall-mounted (standard included), desktop (default support)
I/O		Environment
USB	2xUSB3.0, 6xUSB2.0	Temperature	-20℃~ +60℃, Surface air flow
COM	4xCOM (COM1/2 RS232/485 Optional)	Humidity	5%~95% Non-condensing state
Audio	1xLine out, 1xMIC	Other Function	Power-on, Timing boot, Wake on LAN, PXE boot, watchdog (level 0-255), TPM2.0 security encryption
Power Supply
Power Supply	1xDC Input (5.5x2.5mm), support 12V~19V	Application	Industrial automation, medical, logistics, transportation, warehousing, e-education and other fields

Applications:

Some of the application scenarios for the IEXP-732 include:

Edge Intelligence & Al
Medical Computing Solutions
Intelligent Warehouse
Transportation Systems
